Total Chaos, Heim Joint Upper Control Arms, for Toyota FJ Cruiser & 4Runner

Total Chaos Heim Joint Upper Control Arms

Lifting your vehicle is the first step toward off-road performance, but a lift alone can create alignment limitations. Total Chaos Upper Control Arms (UCAs) are engineered to solve these issues by correcting the caster angle lost during the lifting process. Built from 100% bolt-on 4130 chromoly tubing, these arms are designed to add 3 degrees of caster, significantly improving straight-line tracking, high-speed stability, and cornering performance. Hand-crafted in the U.S.A., they provide the durability and adjustability needed for serious off-road builds.

These arms feature 1" I.D. uniballs with heat-treated stainless-steel components and a military-grade PTFE liner to reduce noise and maintenance. The inclusion of 3/4" chromoly heim joints at the pivots allows for maximum tuning of both caster and camber. Whether you are running a standard 1.5"-3" lift or a 4" or higher drop bracket kit, these UCAs maintain factory alignment specs and are the only arms on the market designed to clear a 3.0" diameter coilover shock without contact.

Features

• Fully Adjustable Heim Pivots: 3/4" chromoly heim joints allow for precise fine-tuning of caster and camber beyond factory limits.
• Corrected Steering Geometry: Adds 3 degrees of caster to eliminate the "darting" or wandering sensation common in lifted Toyotas.
• Increased Wheel Travel: Provides up to 1" of additional droop travel when paired with extended-travel coilover shocks.
• Superior Uniball Design: 1" I.D. stainless-steel uniballs feature a PTFE woven fabric liner for maximum corrosion resistance and longevity.
• Maximum Clearance: Specifically profiled to allow the installation of large-diameter 3.0" coilovers with no component contact.
• Military-Grade Durability: 4130 chromoly tubular construction with a 3-stage powder coat finish for long-lasting protection.
• Grade 8 Hardware: Supplied with a complete high-tensile hardware kit and CNC machined 17-4 stainless-steel high-misalignment spacers.

Spec

• Material: 4130 Chromoly Tubing
• Pivot Type: 3/4" Chromoly Heim Joints
• Joint Type: 1" I.D. Heat-Treated Stainless Steel Uniball
• Vehicle Compatibility: Toyota FJ Cruiser & 4Runner
• Lift Compatibility: 1.5" to 3" Lifts (also fits 4"+ drop bracket lifts)
• Finish: 3-Stage Powder Coat with Durable Clear Coat
• Manufacturing: Hand-crafted in the U.S.A.
